Name: Hall Effect Flange Mount Geartooth Speed Sensor
SKU: SENGTHALL
Price: 74.75 NZD
Availability: InStock

Hall Effect Flange Mount Geartooth Speed Sensor

SKU:

SENGTHALL

Description

Description

Hall effect gear tooth sensor mainly for speed sensing.

Direct physical replacement for the discontinued Honeywell GT101 / 1GT101DC sensor.

Features:

senses ferrous metal targets
digital current sinking output (open collector)
better signal to noise ratio than variable reluctance sensors
excellent low speed performance
output amplitude not dependent on RPM
sensor electronically self-adjusts to slight variations in runout and temperature. simplifying installation and maintenance
fast operating speed - over 100KHz
EMI resistant
reverse polarity protection

Common uses include:

camshaft and crankshaft speed/position
transmission speed
tachometers
anti-skid / traction control
sprocket speed
stop motion detection

Target Material: Ferrous metal (steel)

Operating Temperature: -40 to +125 Degrees C

Supply Voltage: 4.75-24VDC
